High Voltage Tester Variants
High Voltage Tester 10kV AC and DC
SCR Make High Voltage Testing Equipments also known as di-electric withstand tester comes with customized facilities like voltage rampup rate zero interlock, Plus the user may specify the voltage level and leakage milliampere level so as to suit its testing needs.
The setup is designed to carry out the test as per IEC 60335-1 and IS 302-1.
It can be performed using either AC or DC voltage, with the choice depending on the specific application and standards, with AC tests being common for evaluating insulation strength and DC tests for measuring insulation resistance. SCR offer this system in various configurations based on your product & applications as per ASTM , UL, IEC standards.
We can customize the product based on Voltage Level & Leakage Milliampere Level so as to suit its testing needs.
In case of routine testing solution employing mechanical test jigs, the number of MCBs (to be tested simultaneously) can be customized as 1, 4 and 20.
The test bench tests the di-electric withstand capability of the product with settable high voltage and allowable leakage current. Identifying insulation faults, such as short circuits and leakage currents.Verifying that systems meet safety standards and reduce the risk of electrical shocks.Ensuring products meet industry regulations like IEC and UL standards.
SCR ELEKTRONIKS make Programmable High Voltage Tester model: PHVT is the unique High Voltage breakdown tester indispensable for all types of Industrial grade Electrical products manufacturers for carrying out High Voltage Test according to different standards like IEC 60243 & ASTM D 149, Clause No. 12
The test bench tests the di-electric withstand capability of the product with settable high voltage and allowable leakage current. The voltage set can be ramped up slowly with a settable ramp up time so that the user can exactly find the voltage level at which the insulation breakdown takes place.
As per IEC 60243 and IS 302-1, manufacturers need to test solid insulating material for dielectric breakdown voltage. This checking of strength of solid insulating materials is done as per the utility’s frequency. We have a series of High Voltage Testers right from 10kV to 150kV to carry out this dielectric strength test (Hipot)
The source is designed for the capacity as mentioned in clause 6. The equipment provides an electronic circuit for current sensing & tripping. Various tripping current ranges are provided to protect the sample as well as the equipment. The high potential test system is designed for all the methods of voltage applications (voltage profiles) such as short time test, step by step test, slow rate of rise test etc. – thus it caters to requirements of the ASTM D 149 test standard.
This Programmable Unit has facility to carry-out below test :
a) Manual Mode sudden application of test voltage.
b) Auto Mode ( Programmable Mode – PLC or PC)
We have a series of High Voltage Testers right from 2kV to 150kV to carry out this dielectric strength test (Hipot)
The test bench can be customized as per Voltage Level & Leakage Milliampere Level so as to suit its testing needs. Also, All Models can be customized according to AC , DC or both and can also be customized with Micro controller based or PC based.
PC Based System:
The tester is used to test insulation testing of special purpose cables such as armoured cables. It can also be used for conventional cables. The tests covered are time to track method, initial tracking voltage test and erosion test.
High voltage tests, also known as hipot tests, can be performed using either AC or DC voltage, with the choice depending on the specific application and standards, with AC tests being common for evaluating insulation strength and DC tests for measuring insulation resistance. SCR offer this system in various configurations based on your product & applications as per ASTM , UL, IEC standards.
